Description
H3 is an ideal three-way speaker both for indoor and outdoor performance. H3 with one unit compression driver, one unit 10inch woofer for MF and one unit 15inch woofer for LF sound. All the transducers work together for a full range sound system. H3 will deliver the sound at whatever is expected.
Features
- All-horn three-way system.
- Phase-ball loaded MID-driver.
- Fitted with handles and castors.
- Outdoor Speaker Cabinet.
Applications
- Larger club performance.
- Larger scale installs.
| System Type | 15inch, 3-way outdoor speaker. |
| Frequency Response | 50Hz -- 18kHz ± 3dB |
| Sensitivity (1W/1M) | 104 dB. |
| Impedance | 8 ohm |
| Rated Power | 600W (AES), 1200W (PEAK). |
| Dispersion | 80° (H) X 50° (V) |
| Drivers | LF driver 15' ' transducer (75mm) voice coil. |
| HF driver 1.5' ' exit (75mm) voice coil. MF driver 10' ' (65mm) VC | |
| Maximum SPL | 137dB |
| Connectors | 2 x Neutrik NL4. |
| Dimensions | (W) 560mm x (H) 1066mm x (D) 780mm |
| Weight | 77kg |
